Length Customized 100G QSFP28 To QSFP28 AOC Active Optical Cable MMF

Length Customized 100G QSFP28 To QSFP28 AOC Active Optical Cable MMF

Customized 100G QSFP28 To QSFP28 AOC Active Optical Cable MMF

  • China
  • 5-7 workdays





2M (7Ft) 100G QSFP28 To QSFP28 AOC Active Optical Cable Optic Cable MMF



100G QSFP28 AOC is a high data rate parallel active optical cable (AOC), to overcome the bandwidth limitation of traditional copper cable. This product converts the parallel electrical input signals into parallel optical signals (light), by a driven Vertical Cavity Surface Emitting Laser (VCSEL) array. The light propagates through the ribbon fiber individually, and be captured by the photo diode array. The optical signals are converted into parallel electrical signals and outputted. Consequently, each terminal of the cable has 8 ports, 4 for data transmission and 4 for data receiving, to provide totally 100Gb/s data exchange.

The AOC offers 4 independent data transmission channels and 4 data receiving channels via the multimode ribbon fibers, each capable of 25Gb/s operation. Consequently, an aggregate data rate of 100Gb/s over 100 meters transmission can be achieved by this product, to support the ultra-fast computing data exchange.

The product is designed with form factor, optical/electrical connection according to the QSFP Multi-Source Agreement (MSA). It has been designed to meet the harshest external operating conditions including temperature, humidity and EMI interference.

LANMexx provides  AOC compatible with Cisco, Huawei,  Extreme, HP, Finisar, Broadcom, Foundry, Alcatel,  D-link,  Enterasys,  Netgear, Juniper, Nortel, IBM, Gigamon, Linksys, Arista, HW  and etc.



Features:

  • Full Duplex 4 Channel 850nm Parallel Active Optical Cable
  • 4 independent full-duplex channels
  • Up to 25.78Gb/s data rate per channel
  • QSFP MSA compliant
  • Up to 100m OM4 MMF transmission
  • Operating case temperature: 0 to 70oC
  • Single 3.3V power supply
  • Maximum power consumption 3.5W each terminal
  • RoHS-6 compliant

Specification

Series Product Description

100G AOC

QSFP28 to QSFP28

QSFP28 to QSFP28, 100Gb/s, AOC, 1M, MMF
QSFP28 to QSFP28, 100Gb/s, AOC, 2M, MMF
QSFP28 to QSFP28, 100Gb/s, AOC, 3M, MMF
QSFP28 to QSFP28, 100Gb/s, AOC, 5M, MMF
QSFP28 to QSFP28, 100Gb/s, AOC, 7M, MMF
QSFP28 to QSFP28, 100Gb/s, AOC, 10M, MMF
QSFP28 to QSFP28, 100Gb/s, AOC, 15M, MMF
QSFP28 to QSFP28, 100Gb/s, AOC, 20M, MMF

    Cable Length and Label could be customized on request.



Application

  • 100G Ethernet
  • Infiniband EDR

Compatiable brand

QSFP+ to 8 x LC Connector Breakout Optical Cable For  Data Center



6 + 2 =

100Gbps QSFP28 Active Optical Cable 100G QSFP28-100G QSFP28 AOC Cable 5Meter OM3

100Gbps QSFP28 Active Optical Cable 100G QSFP28-100G QSFP28 AOC Cable 5Meter OM3

100Gbps QSFP28 Active Optical Cable 100G QSFP28-100G QSFP28 AOC Cable 5Meter OM3

  • China
  • 5-7 workdays





100G QSFP28 to QSF28 active optical cable 1-20m OM3, QSFP28 100G AOC Cable



100G QSFP28 AOC is a high data rate parallel active optical cable (AOC), to overcome the bandwidth limitation of traditional copper cable. This product converts the parallel electrical input signals into parallel optical signals (light), by a driven Vertical Cavity Surface Emitting Laser (VCSEL) array. The light propagates through the ribbon fiber individually, and be captured by the photo diode array. The optical signals are converted into parallel electrical signals and outputted. Consequently, each terminal of the cable has 8 ports, 4 for data transmission and 4 for data receiving, to provide totally 100Gb/s data exchange.

 The AOC offers 4 independent data transmission channels and 4 data receiving channels via the multimode ribbon fibers, each capable of 25Gb/s operation. Consequently, an aggregate data rate of 100Gb/s over 100 meters transmission can be achieved by this product, to support the ultra-fast computing data exchange.

 The product is designed with form factor, optical/electrical connection according to the QSFP Multi-Source Agreement (MSA). It has been designed to meet the harshest external operating conditions including temperature, humidity and EMI interference.

LANMexx provides  AOC compatible with Cisco, Huawei,  Extreme, HP, Finisar, Broadcom, Foundry, Alcatel,  D-link,  Enterasys,  Netgear, Juniper, Nortel, IBM, Gigamon, Linksys, Arista, HW  and etc.



Features:

  • Full Duplex 4 Channel 850nm Parallel Active Optical Cable
  • 4 independent full-duplex channels
  • Up to 25.78Gb/s data rate per channel
  • QSFP MSA compliant
  • Up to 100m OM4 MMF transmission
  • Operating case temperature: 0 to 70oC
  • Single 3.3V power supply
  • Maximum power consumption 3.5W each terminal
  • RoHS-6 compliant

Specification

Series Product Description

100G AOC

QSFP28 to QSFP28

QSFP28 to QSFP28, 100Gb/s, AOC, 1M, MMF
QSFP28 to QSFP28, 100Gb/s, AOC, 2M, MMF
QSFP28 to QSFP28, 100Gb/s, AOC, 3M, MMF
QSFP28 to QSFP28, 100Gb/s, AOC, 5M, MMF
QSFP28 to QSFP28, 100Gb/s, AOC, 7M, MMF
QSFP28 to QSFP28, 100Gb/s, AOC, 10M, MMF
QSFP28 to QSFP28, 100Gb/s, AOC, 15M, MMF
QSFP28 to QSFP28, 100Gb/s, AOC, 20M, MMF

    Cable Length and Label could be customized on request.



Application

  • 100G Ethernet
  • Infiniband EDR

Compatiable brand

QSFP+ to 8 x LC Connector Breakout Optical Cable For  Data Center



10 + 10 =

Active Optical Cable,25G SFP28 AOC,SFP28 Active Optical Cable

Active Optical Cable,25G SFP28 AOC,SFP28 Active Optical Cable

25G SFP28 Active optical cable 300M 850nm AOC 850nm

SFP28, 25G Active Optical Cable (AOC). 25Gbase-SR, AOC.



1. Applications
25GBASE-SR Ethernet
Servers,switches,storage and host card adapters

2. Features
Electrical interface compliant to SFF-8431
850nm VCSEL laser and PIN photo-detector
Maximum link length of 70m on OM3 MMF and 100m on OM4 MMF
Digital diagnostics functions are available via the I2C interface
Operating case temperature Commercial: 0°C to +70 °C
+3.3V single power supply
Power consumption less than 1W
RoHS compliant
Password protection for A0h and A2h

3. Description
LANMexx-25G-AOC SFP28 Active Optical Cable (AOC) is a 25Gbps solution to25G Ethernet, and datacenter.

The integrated cable transmits 25Gbps data in each direction over MMF with distance up to 100m. The AOC is SFP+ MSA compliance, low power consumption and lightweight.

4. standard
Compliant with SFF-8431 and SFF-8432
Compliant with SFF-8472 Rev 10.2
RoHS Compliant





Compatiable brand

QSFP+ to 8 x LC Connector Breakout Optical Cable For  Data Center





LANMexx  also provides a full set of OEM services, such as fiber connector, length, color, fiber grade, specification, material, package etc.

Please feel free to contact  sales@szlanmexx.com





Compatible AOC 25G SFP28 Active Optical Cable

Compatible AOC 25G SFP28 Active Optical Cable

25G SFP28 AOC Active Optical Cable

SFP28, 25G Active Optical Cable (AOC). 25Gbase-SR, AOC.



1. Applications
25GBASE-SR Ethernet
Servers,switches,storage and host card adapters

2. Features
Electrical interface compliant to SFF-8431
850nm VCSEL laser and PIN photo-detector
Maximum link length of 70m on OM3 MMF and 100m on OM4 MMF
Digital diagnostics functions are available via the I2C interface
Operating case temperature Commercial: 0°C to +70 °C
+3.3V single power supply
Power consumption less than 1W
RoHS compliant
Password protection for A0h and A2h

3. Description
LANMexx-25G-AOC SFP28 Active Optical Cable (AOC) is a 25Gbps solution to25G Ethernet, and datacenter.

The integrated cable transmits 25Gbps data in each direction over MMF with distance up to 100m. The AOC is SFP+ MSA compliance, low power consumption and lightweight.

4. standard
Compliant with SFF-8431 and SFF-8432
Compliant with SFF-8472 Rev 10.2
RoHS Compliant



Compatiable brand

QSFP+ to 8 x LC Connector Breakout Optical Cable For  Data Center





LANMexx  also provides a full set of OEM services, such as fiber connector, length, color, fiber grade, specification, material, package etc.

Please feel free to contact  sales@szlanmexx.com





Mellanox MC220731V-020 Compatible 56G QSFP+ AOC (Active Optical Cable)

Mellanox MC220731V-020 Compatible 56G QSFP+ AOC (Active Optical Cable)

56GBase-AOC QSFP+ to QSFP+ Active Optical

56GBASE QSFP+ to QSFP+ 5M Active Optical Cable 56G QSFP+ AOC OM3 Multimode Fiber Cables Arista HP Mellanox Generic Compatible QSFP-H56G-AOC5M

56Gbps QSFP+ Active Optical Cable

  1. Applications
    * Low-latency and high-speed interconnections for high performance computing(HPC)
    * 40G Ethernet SR4
    * Infiniband 56Gbase QSFP+
    * Other high-throughput data transmission network
    * Storage area Network(SAN)
    2. Features
    * Quad Small Form-factor Pluggable (QSFP)
    * 40GBASE-SR4 compliant
    * FDR (Infiniband) compliant
    * Bi-directional parallel link
    * 16Gb/s per lane, x4 channels
    * Up to 100m
    * Low profile connectors
    * Low power consumption
    * Bundle multi-mode fiber array
    * 850nm VCSEL four array
    * PIN diode four array
    * Hot-Pluggable
    * I2C management interface
    * From 0 to 70 degree case temperature
    * 3V power supply voltage
    * Electrical 38-pin connector

100G QSFP28 to 2x 50G QSFP28 AOC Active Optical CableExtreme Networks Compatible 100G QSFP28 to 4x25G SFP28 Breakout Active Optical Cable

Compatiable brand

QSFP+ to 8 x LC Connector Breakout Optical Cable For  Data Center

Order  information





Package

Data Rate

Reach

Fiber Type

56G SFP+ AOC

56G QSFP-QSFP AOC 1M

56Gb/s

1m

OM2/OM3

56G QSFP-QSFP AOC 2M

56Gb/s

2m

OM2/OM3

56G QSFP-QSFP AOC 3M

56Gb/s

3m

OM2/OM3

56G QSFP-QSFP AOC 5M

56Gb/s

5m

OM2/OM3

56G QSFP-QSFP AOC 7M

56Gb/s

7m

OM2/OM3

56G QSFP-QSFP AOC 10M

56Gb/s

10m

OM2/OM3

56G QSFP-QSFP AOC 15M

56Gb/s

15m

OM2/OM3

56G QSFP-QSFP AOC  20M

56Gb/s

20m

OM2/OM3



LANMexx  also provides a full set of OEM services, such as fiber connector, length, color, fiber grade, specification, material, package etc.

Please feel free to contact  sales@szlanmexx.com





40G QSFP+ to 4xSFP+ Breakout Active Optical Cable (AOC)

40G QSFP+ to 4xSFP+ Breakout Active Optical Cable (AOC)

40G QSFP+ to 4 x 10G SFP+ AOC 850nm OM3 Cable

40G QSFP+ to 4x10G SFP+ AOC Multimode Breakout Active Optical Cable

OM3/OM4 MMF For Ethernet and Data Center 850nm



QSFP+ AOC end:

  • Compliant to the 40GBASE-SR4 and XLPPI

Specification per IEEE 802.3ba-2010 and supporting

40G-IB-QDR / 20G-IB-DDR / 10G-IB-SDR applications

  • Compliant to the industry standard SFF-8436

QSFP+ Specification

  • Power Level 1: Max Power < 1.5 W
  • Operate at 10.3125 Gbps per channel with 64b/66b

encoded data for 40GbE application and at 10 Gbps

with 8b/10b compatible encoded data for 40G-IB-QDR application

Each 4× SFP+ end:

  • Compliant to the electrical specifications per SFF-8431 Specifications for Enhanced Small Form Factor Pluggable Module
  • Mechanical specifications per SFF Committee SFF-8432 Improved Pluggable Form factor “IPF”
  • Maximum power dissipation 0.35W per end.

Active Optical Cable Assembly:

  • 0 to 70C degree case temperature operating range
  • Proven High Reliability 850 nm technology
  • Hot pluggable for ease of servicing and installation
  • Two Wire Serialinterface
  • Utilizes optical fiber for high density and thin, lightweight cable management

Applications

  • 40GbE and 10GbE break-out applications for Datacom switch and router connections
  • 40G to 4×10G density applications for Datacom and Proprietary protocol applications
  • Datacenter

Description

The LX-4SFPAOC-XXXC is a Four-Channel, Pluggable, Parallel, Fiber-Optic QSFP+ Active Optical Cable (AOC) to 4× SFP+ Active Optical Cable break-out solution. This Breakout cable is intended for 40G to 4× 10G applications.

This AOC is a high performance cable for short-range multi-lane data communication and interconnect applications. It integrates four data lanes in each direction with 40 Gbps aggregate bandwidth. Each lane can operate at 10.3125 Gbps. These cables also support 4 x 10G InfiniBand QDR applications and are backwards compatible to the 4 × 5G IB DDR and 4 × 2.5G IB single IB SDR applications.

This product is leveraged from LANMexx QSFP+ to QSFP+ Active Optical Cable product and SFP+ Active Optical Cable product. Where applicable, consult these respective datasheets

This AOC incorporates LANMexx’ proven integrated circuit and VCSEL technology to provide reliable long life, high performance, and consistent service.



Compatiable brand

QSFP+ to 8 x LC Connector Breakout Optical Cable For  Data Center

Order  information

40G QSFP+AOC



Part No. Form Factor Data Rate Distance Wavelength Connector
QSFP-40G-AOC3M QSFP+ 40G/ps 3M N/A QSFP+/QSFP+
QSFP-40G-AOC5M QSFP+ 40G/ps 5M N/A QSFP+/QSFP+
QSFP-40G-AOC7M QSFP+ 40G/ps 7M N/A QSFP+/QSFP+
QSFP-40G-AOC10M QSFP+ 40G/ps 10M N/A QSFP+/QSFP+
QSFP-40G-AOC15M QSFP+ 40G/ps 15M N/A QSFP+/QSFP+
QSFP-40G-AOC20M QSFP+ 40G/ps 20M N/A QSFP+/QSFP+
QSFP-40G-AOC50M QSFP+ 40G/ps 50M N/A QSFP+/QSFP+
QSFP-40G-AOC100M QSFP+ 40G/ps 100M N/A QSFP+/QSFP+
QSFP-40G/4SFP-AOC3M QSFP+ 40G/ps 3M

OM1

OM3

QSFP/4SFP
QSFP-40G/4SFP-AOC5M QSFP+ 40G/ps 5M

OM1

OM3

QSFP/4SFP
QSFP-40G/4SFP-AOC6M QSFP+ 40G/ps 6M

OM1

OM3

QSFP/4SFP
QSFP-40G/4SFP-AOC7M QSFP+ 40G/ps 7M

OM1

OM3

QSFP/4SFP
QSFP-40G/4SFP-AOC8M QSFP+ 40G/ps 8M

OM1

OM3

QSFP/4SFP
QSFP-40G/4SFP-AOC10M QSFP+ 40G/ps 10M

OM1

OM3

QSFP/4SFP
QSFP-40G/4SFP-AOC15M QSFP+ 40G/ps 15M OM1/OM3 QSFP/4SFP
QSFP-40G/8LC-AOC5M QSFP+ 40G/ps 5M OM3 QSFP+/8LC
QSFP-40G/8LC-AOC10M QSFP+ 40G/ps 10M OM3 QSFP+/8LC
QSFP-40G/8LC-AOC15M QSFP+ 40G/ps 15M OM3 QSFP+/8LC
QSFP-40G/8LC-AOC20M QSFP+ 40G/ps 20M OM3 QSFP+/8LC





LANMexx  also provides a full set of OEM services, such as fiber connector, length, color, fiber grade, specification, material, package etc.

Please feel free to contact  sales@szlanmexx.com
